Vehicle Care 9-43
Mini-Fuses Usage
DRL/WSW
Daytime Running
Lamps/Windshield
Washer Pump
ECM
Engine Control
Module (ECM)
ECM/
TCM IGN
ECM, Transmission
Control
Module (TCM),
Instrument Panel
Cluster (IPC),
PASS-Key III+
Module
EMIS 1 Emission 1
EMIS 2 Emission 2
EVEN
COILS
Even Coils
FRT FOG Front Fog Lamps
HDLP
WASH
Not Used
HORN Horn
Mini-Fuses Usage
LO BEAM
DRL LEFT
Low-Beam
Daytime Running
Lamps (Left)
LT
HI BEAM
Left High-Beam
Headlamp
LT
LO BEAM
Left Low-Beam
Headlamp
LTR Cigarette Lighter
MISC IGN Ignition
NAV MTR Navigation Motor
ODD COILS Odd Coils
PED PRO Not Used
PWR
MODING
PassKey Module,
Body Control
Module
RT
HI BEAM
Right High-Beam
Headlamp
RT
LO BEAM
Right Low-Beam
Headlamp
RT
LO BEAM
Right Low-Beam
Headlamp
Mini-Fuses Usage
SPARE Spare
SPARE Spare
STR/WHL/
CNTRL
Steering Wheel
Illumination
TCM BATT
Transmission
Control Module
Battery
TOSS/BRK
VAC RLY
Transmission Output
Speed Sensor/Brake
Vacuum Relay
WPR Windshield Wiper
SPARE Spare
J-Case
Fuses
Usage
ABS MTR ABS Motor
BLWR Blower
BRK
VAC PUMP
Brake
Vacuum Pump
EPB Not Used
