A-3
MIDI Data Format
417A-E–069A
n ....... Voice Channel Number = 0H to FH (Ch1 to Ch16)
vv .... Pan = 00H (left) to 40H (center) to 7FH (right)
Expression Controller
★
Format
n ....... Voice Channel Number = 0H to FH (Ch1 to Ch16)
vv .... Expression = 00H to 7FH
Hold 1 (Damper Pedal)
Format
Recognition
n ....... Voice Channel Number = 0H to FH (Ch1 to Ch16)
vv .... Hold 1 = 00H to 7FH (00H to 3FH:OFF, 40H to
7FH:ON)
Send
n ....... Voice Channel Number = 0H to FH (Ch1 to Ch16)
vv .... Hold 1 = 00H,7FH(00H:OFF, 7FH:ON)
Portamento
★
Format
Recognition
n ....... Voice Channel Number = 0H to FH (Ch1 to Ch16)
vv .... Portamento = 00H to 7FH (00H to 3FH:OFF, 40H
to 7FH:ON)
n ....... Voice Channel Number = 0H to FH (Ch1 to Ch16)
vv .... Volume = 00H to 7FH
Pan
★
Format
Byte 1 Byte 2 Byte 3
BnH 07H vvH
Recognition
n ....... Voice Channel Number = 0H to FH (Ch1 to Ch16)
vv .... Sostenuto = 00H to 7FH (00H to 3FH:OFF, 40H to
7FH:ON)
Send
n ....... Voice Channel Number = 0H to FH (Ch1 to Ch16)
vv .... Sostenuto = 00H, 7FH (00H:OFF, 7FH:ON)
Soft
Format
Recognition
n ....... Voice Channel Number = 0H to FH (Ch1 to Ch16)
vv .... Soft = 00H to 7FH (00H to 3FH:OFF, 40H to
7FH:ON)
Send
n ....... Voice Channel Number = 0H to FH (Ch1 to Ch16)
vv .... Soft = 00H, 7FH(00H:OFF, 7FH:ON)
Resonance
★
Format
n ....... Voice Channel Number = 0H to FH (Ch1 to Ch16)
vv .... Filter Resonance = 00H to 7FH
Release Time
★
Format
Channel Volume
★
Format
Sostenuto
Format
n ....... Voice Channel Number = 0H to FH (Ch1 to Ch16)
vv .... AMP Release Time = 00H to 7FH
Attack Time
★
Format
n ....... Voice Channel Number = 0H to FH (Ch1 to Ch16)
vv .... AMP Attack Time = 00H to 7FH
Byte 1 Byte 2 Byte 3
BnH 0AH vvH
Byte 1 Byte 2 Byte 3
BnH 0BH vvH
Byte 1 Byte 2 Byte 3
BnH 40H vvH
Byte 1 Byte 2 Byte 3
BnH 41H vvH
Byte 1 Byte 2 Byte 3
BnH 42H vvH
Byte 1 Byte 2 Byte 3
BnH 43H vvH
Byte 1 Byte 2 Byte 3
BnH 47H vvH
Byte 1 Byte 2 Byte 3
BnH 48H vvH
Byte 1 Byte 2 Byte 3
BnH 49H vvH
