E-29
Assembly Instructions
Figure 7
417A-E-031A
Protecting the Piano Against Tipping
Over
Locating the piano against a wall is normally enough to
protect it against tipping over. If you need to locate it away
from a wall, be sure to perform the following steps in order
to ensure that it is secure.
1. Remove the metal pieces at the bottom of side panels A
and B.
2. Repositioning the metal pieces so they are facing outwards
reinstall them onto the side panels (Figure 7).
• If you have trouble inserting the bolts that come pre-
installed in the side panels into the joint connector screw
holes, use a screwdriver to rotate the joint connector so
the bolts can enter the holes (
★
in Figure 7).
Attaching the AC Adaptor and
Pedal to the Piano
After assembling the stand, connect the AC adaptor and pedal
to the bottom of the piano. For details, see “Power Supply”
on page E-10 and “Connections” on page E-11.
Side panel
