Getting Started With Your System
39
Server Enclosure Specifications
Physical
Height 17.5 cm (6.9 in.)
Width 44.7 cm (17.6 in.)
Depth 81.3 cm (32.0 in.)
Weight (empty) 17.93 kg (39.53 lbs.)
Sled Support
Server enclosure with internal
power source • Up to 8 C8220 single-wide compute sleds
• Up to 4 C8220X double-wide compute sleds
• Up to 4 C8000XD storage sleds
• Up to 2 power sleds
Server enclosure with external
PDU • Up to 10 C8220 single-wide compute sleds
• Up to 5 C8220X double-wide compute sleds
• Up to 5 C8000XD storage sleds
Interfaces
NIC Two 10/100Mbit NIC ports (1 front, 1 back)
Serial 1 back
Power/event LED 2 (1 front, 1 back)
UID LED 2 (1 front, 1 back)
Ethernet activity LED 1 front
Thermal sensor 1 front
System fan module failure LED 3 back
System fans
Fan type 3 fan modules (2 fans per module/6 total)
Power
DC power supply
Voltage
with external PDU 12 V DC, 50–60 Hz, 680 A max with 6 PSU
populated
