16
Getting Started With Your System
3 Remove the power cable interface box (PCIB) module.
a Remove the two screws ‚ securing the PCIB module.
b Grasp the PCIB handle and pull it out of it’s bay —.
4 Attach the mounting brackets to the sides of the PDU.
a Affix the ten screws
‚ to the left and right sides of the PDU.
b Position the left mounting bracket marked "L" to align the screw holes
with the screws on the PDU and slide the mounting bracket toward
the back of the PDU until it locks into place
—.
c Position the right mounting bracket marked "R" to align the screw
holes with the screws on the PDU and slide the mounting bracket
toward the back of the PDU until it locks into place
—.
2
1
