Getting Started With Your System
25
To connect multiple server enclosures to the PDU:
a Secure the first server enclosure’s three black power cable lugs ‚ to
the top power bus bar (GND) with the three screws š.
b Secure the first server enclosure’s three yellow power cable lugs — to
the bottom power bus bar with the three screws š.
c Secure the second server enclosure’s three black power cable lugs ˜ to
the top power bus bar (GND) with the three screws š.
d Secure the second server enclosure’s three yellow power cable lugs ™
to the bottom power bus bar with the three screws š.
3
2
1
