Product Specification
VisiLine– Innovative functionality
Flexible assembly ▪
RGB and YUV interpolation algorithms on board ▪
Bandwidth up to 1000 Mbit/sec for fast multi-camera operation ▪
Flexible system architecture due to cable length up to 100 m ▪
Baumer driver for reliable image transfer ▪
PoE (Power over Ethernet) ▪
Camera Type
Sensor
Size
Resolution
Full Frames
[max. fps]
CCD Sensor (monochrome / color)
VLG-02M / VLG-02C 1/4" 656 x 490 160
VLG-12M / VLG-12C 1/3" 1288 x 960 42
VLG-20M / VLG-20C 1/1.8" 1624 x 1228 27
CMOS Sensor (monochrome / color)
VLG-22M / VLG-22C 2/3" 2044 x 1084 55
VLG-40M / VLG-40C 1" 2044 x 2044 29
System Requirements
Single-camera system Multi-camera system
Minimum Recommended Minimum Recommended
CPU Intel ® Pentium ® 4
or comparable
processor
Intel ® Core™ Duo comparable processor
Clock 2.5 GHz > 2.5 GHz 2.5 GHz 3 GHz
RAM 1024 MB 2048 MB 2048 MB > 2048 MB
Operating
system
(OS)
Microsoft ® Windows ® XP incl. Service Pack 2 or higher
Microsoft ® Windows ® XP x64 incl. Service Pack 2 or higher
Microsoft ® Windows Vista™ 32 / 64 bit systems
Microsoft ® Windows 7 32 / 64 bit systems
Linux ® 32 / 64 bit systems from Kernel 2.6.xx
Graphic recommended resolution 1280 x 1024, color depth at least 16 bit
Ethernet Gigabit Ethernet compliant NIC (recommended Intel ® chipset)
Framework
(optional)
Windows ® OS: NET™ Framework 2 0 or higher
Linux ® OS: Mono 1 2.4 or higher
Dimensions
temperature
measurement point
Front View Side View Back View
Bottom View
C Mount
2 M3 depth 3
2 M3 depth 3
2 M2 depth 3
Pixel 0,0
2 M3 depth 3
4 M3 depth 3
8 7 8 7 15 6
20
9,3
3,5
26
14 5 48 3 9 6
33
33
26 12
3,5
8,6
26
26
30
ø
Safety
Further Information
For further information on our products visit www.baumer.com
For technical issues, please contact our technical support:
[email protected] Phone +49 (0)3528 4386-0 Fax +49 (0)3528 4386-86
© Baumer Optronic GmbH Badstrasse 30 DE-01454 Radeberg, Germany
Technical data has been fully checked, but accuracy of printed matter not guaranteed.
Subject to change without notice. Printed in Germany 02/14. v1.2 11107528
FCC – Class B device
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential environment. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed
and used in accordance with the instructios, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occure in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off an on, the user
is encouraged to try to correct the interference by one or
more of the following measures:
Reorient or relocate the receiving antenna. ▪
Increase the separation between the equipment and the ▪
receiver.
Connect the equipment into an outlet on a circuit different ▪
from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician ▪
for help.
Conformity:
CE, FCC Part 15 Class B, RoHS
Notice
Further technical details are
available in the respective
data sheet.
Safety Precautions
Notice
See User s Guide for the com-
plete safety instructions!
Protect the sensor from dirt and ▪
moisture.
Avoid camera contamination by ▪
foreign objects.
Environmental Requirements
Storage temp. -10°C ... +70°C
Operating temp. see Heat Trans-
mission
Humidity 10 % ... 90 %
Non-condensing
