Kraus FVS-1002 - Manual (Page 5)

Dimension Drawings
Safety Tips
•
Do not overtighten fixing screws/nuts. Tighten finger-tight, then use a wrench/
screwdriver to tighten the fixing screw/nut until snug
1
2
3
4
5
6
7
8
9
Flush the
pipes
Do
not
Disassemble
Hot Water Cold Water
348
109 226
60 º
4 9/32” 8 7/8”
13 11/16”
Max x 35 Max
1 3/8”
Ш33-Ш35
Ш1 5/6”~Ш1 3/8”
(Suggested)
Ш1.29”~Ш1.37”
Ш33~Ш35 hole
