For single-hole installation:
Deck plate (3A), base plate
(3B), and silicone sealant
are NOT required
Step 3: Install faucet and mounting hardware
Insert faucet body (2) into
hole in countertop or deck
plate assembly (3). Install
mounting hardware (4A, B
&C) from underneath the
countertop
Step 2B: Faucet installation - without deck plate
STEP1 STEP 2A STEP 2B STEP 3
STEP 4 STEP 5
STEP 6 STEP 7
STEP 8
