Manifold:
• Manifold Material:
Acetal Copolymer
• Sealing O-rings
Viton
• Fixed tip Material:
Stainless Steel
Section 4.3 - Dimensions:
• 12.34”H X 11.11”W X 14.98”D
• Weight – 10LBS
Section 4.4 - Electrical:
• Power Input:
120VAC/240VAC, 50/60Hz
• Fuses:
Two 2A time delay, 5mm x 20mm fuse
• Grounding:
Through the power cord, must be properly
earth grounded
• Computer Interface:
RS-232 straight through serial cable
Section 4.5 - Environmental:
• Operating Temperature:
15° to 40°C (59° to 104°F)
• Operating Humidity:
0 to 85%, no condensation
• Storage Temperature:
-20° to 65°C (-4° to 149°F)
• Altitude:
Up to 2000m
Section 4.6 - Pneumatic:
• Air Supply:
40 – 80psi; 1 SCFM
• Vacuum:
-25 in. Hg (min); 1.2 SCFM
