Compaq PRESIGNIA DESKTOP COMPUTER 320 - Manual (Page 10)

..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
..
.
Q
UICK
S
PECS
Technical Specification
10 2Q 1999 Division – SMB - CTO
Compaq Prosignia
Desktop 320
Configured to Order
32X Max 3 CD-ROM
Drive IDE
Disk
Applicable Disk CD-ROM (Mode 1 and 2)
CD-DA, CD-XA, CD-RW (Mode 2, Form 1 and 2)
Photo CD (Single and Multi-session)
Mixed Mode (Audio and Data combined)
CDi Ready
Capacity 650 MB (Mode 1, 12 cm)
Diameter
Rotational Speed
Center Hole
Thickness
Track Pitch 4.7 in, 3.15 in/12 cm, 8 cm
4200 rpm maximum
0.6 in/15 mm diameter
0.05 in/1.2 mm
1.6 µm
Block Size
Mode 1
Mode 2
CD-DA
CD-XA 2,048, 1,024 bytes
2,340, 2,336, 1,024 bytes
2,352 bytes
2,328 bytes
Interface IDE
Access Times (typical)
Random < 100 ms
Full-Stroke < 150 ms
Audio Output Level
Line-Out 0.7 VRMS at 47 kOhms
Headphone 0.6 VRMS at 32 Ohms (maximum volume)
Data Transfer Rate
Sustained 150 KB/s (single)
Burst 1500 to 4800 KB/s (variable)
Cache Buffer 128 KB
Start-up Time (typical) < 7 seconds
Stop Time < 4 seconds
Laser Parameters
Type Semiconductor Laser GaA1As
Wave Length 780 ± 25 nm
Divergence Angle 53.5° ± 1.5°
Output Power 0.14 mW
Operating Conditions
Temperature 41° to 113°F/5° to 45°C
Humidity 10% to 80%
Dimensions
(HxWxD, maximum) 11.69 x 5.91 x 8.2 in/4.29 x 15.01 x 20.8 cm
Weight 2.65 lbs/1.2 kg
