MANUAL HEATING AND AIR CONDITIONING SYSTEM
A. Defrost: Distributes air through the windshield defroster vents and
de-mister vents. This setting can also be used to defog and clear the
windshield of a thin covering of ice.
B. Rear defrost: Turns the heated rear window on and off. Refer to
Heated rear window later in this chapter for more information.
C. Air distribution control: You can set the air distribution control to
any position between the symbols.
Distributes air through the windshield defroster vents, de-mister
vents and floor vents.
Distributes air through the instrument panel vents.
Distributes air through the instrument panel vents, floor vents,
and de-mister vents.
Distributes air through the floor vents.
A B C D E
I
K
J
F
G
H
R
MAX
A/C
A/C
130 Climate Control
