FORD 2013 F-150 v.3 - Manual (Page 317)

Fuse or relay
number
Fuse amp
rating
Protected components
10 10A Run/accessory relay
11 10A Instrument cluster
12 15A Interior lighting, Puddle lamps,
Backlighting, Cargo lamp
13 15A Right turn signals/stop lamps
14 15A Left turn signals/stop lamps
15 15A Reverse lights, High-mounted stop
lamp
16 10A Right low-beam headlamp
17 10A Left low-beam headlamp
18 10A Brake-shift interlock, Keypad
illumination, Powertrain control
module wakeup, Passive anti-theft
system
19 20A Audio amplifier
20 20A Power door locks
21 10A Not used (spare)
22 20A Horn
23 15A Steering wheel control module
24 15A Datalink connector, Steering
wheel control module
25 15A Not used (spare)
26 5A Radio frequency module
27 20A Not used (spare)
28 15A Ignition switch
29 20A Radio
30 15A Front parking lamps
31 5A Brake on/off – Instrument panel,
Engine
316 Fuses
2013 F-150 (f12)
Owners Guide gf, 3rd Printing, February 2013
USA (fus)
