Instrument cluster
1 Fuel gauge 74
2 Speedometer
3 Indicator/warning lamps
14
4 Tachometer 75
5 Engine oil temperature 75
6 External temperature 75
7 Electronic displays 16
8 Miles, trip miles 76
9 Clock 79
10 Reset miles 76
Indicator/warning lamps
Instrument cluster
The indicator and warning lamps can light up in
a variety of combinations and colors.
Several of the lamps are checked for proper
functioning when the engine is started or the ig‐
nition is switched on, and light up briefly in the
process.
Overview: indicator/warning lamps
Symbol Function or system
Turn signal
Parking brake
Parking brake in Canadian models
Automatic Hold*
Front fog lamps*
Seite 14
14
Online Edition for Part no. 01 40 2 606 521 - 03 11 490
Cockpit
