Crown Audio 800CSL User Manual
Page 33
Power Base-2 & 800CSL Amplifier Service Manual
33
INTERCONNECTS
J1
C 7593-4
HEADER 5 PIN
J2
C 4508-5
16 PIN SOCKET
J9
C 7527-2
HEADER 6 PIN
J10
C 7592-6
HEADER 4 PIN
J11
C 7526-4
HEADER 3 PIN
J100
J200
C 6777-4
PHONE JACK
J500
J800
D 6619-7
10" RIBBON ASSY
J600
J700
D 6620-5
6" RIBBON ASSY
MISC.
BOARD
D 7251-8
MOUNTS U1, U2:
(2)
C 1889-2
6-32 NUT
(2)
C 2176-3
6-32 X .5 SCREW
(2)
C 5341-0
HEATSINK
(2)
C 5594-4
STAR WASHER
MOUNTS U104, U204:
(2)
C 3450-1
14 PIN SOCKET
COVERS FOR J100, J200:
(2)
C 6778-2
Phone Jack Cover
STRAIN RELIEF:
(4)
C 1811-6
CABLE TIE
Q42818-7 Main Module Parts List (D 7251-8 Board)
