Power Base-2 & 800CSL Amplifier Service Manual
17
Mechanical (Non-Module) Parts
SUPPLIMENTAL ITEMS
CPN
ITEM
QTY
D 4137-2
Nylon Thumbscrew Washer
4
C 3342-0
Feet, Black Self-Stick
4
A10087-71012
10-32 .75 Machine (Rack Screw)
4
120VAC/60HZ NORTH AMERICA PRODUCT ONLY
CPN
ITEM
QTY
A10089-10832
Screw, 8-32 2.0 Ph Machine
4
A10285-28
Fuse, 20A 3AB (120V Units)
1
A10285-7
Fuse, .5A AGC 1.25x.25 (LVPS)
1
D 6748-4
PB-2 Power Transformer
1
A10089-10832
Screw, 8-32 2.0 Ph Mach
4
A10101-19
Washer, Fiber (XFMR Assby)
2
H42873-2
Fanformer Assembly
1
P10426-8
Fuse Board (International Only)
1
P10125-6
Fuse Board (U.S. Only)
1
FANFORMER MECHANICAL ASSEMBLY
CPN
ITEM
QTY
C 7062-0
Screw, 6-32-5/16 Flat Mach
2
C 9939-7
Fan Blade, 4 inch CCW
1
D 8439-8
Fan Bracket
1
FILTER CAPACITOR MOUNTING ASSEMBLY (ONE PER CHANNEL)
CPN
ITEM
QTY
A10095-4
Washer, #10 Ext. Lock
2
A10098-5
Belleville Spring Washer
2
C 8433-2
C126/C226 10,000µF 110V
1
C 8752-5
D117/D217 35A 400V Bridge Rectifier
1
C 9870-4
Screw, 10-32-.38 Pan
2
D 6764-1
Washer, Shoulder
2
D 8438-0
Bracket, Capacitor Mounting
1
FUSE BOARD ASSEMBLY
CPN
ITEM
QTY
C 5060-6
Fuse Clip, PC Mount #926
4
P10426-8
Fuse Board (International Only)
1
P10125-6
Fuse Board (U.S. Only)
1
LED ASSEMBLY
CPN
ITEM
QTY
C 4342-9
Enable LED, Amber
1
P10068B4
LED Board
1
