Features:
• Fixed-angle rotor for spinning 75 mm, 100 mm and 125 mm test tubes in
specially designed tube holders
• Cool–Flow air flow design that prevents overheating of samples
• Heavy gauge steel construction for safety and durability
• Lid safety switch that prevents the centrifuge from operating unless the
lid is closed and latched
• Removable rotor for easy cleaning
• Brushless A/C motor
• Clear lid for safe observation of samples and optical calibration of speed
Page 3
Specifications:
General Specifications for the Model 614B Centrifuge
Nominal Speed (125 mm holders): 3,150 (± 100) RPM
Nominal RCF (125 mm holders): 1,200 (± 80) xg
Nominal Speed (100 mm holders): 3,250 (± 100) RPM
Nominal RCF (100 mm holders): 1,080 (± 80) xg
Nominal Speed (75 mm holders): 3,300 (± 100) RPM
Nominal RCF (75 mm holders): 950 (± 80) xg
Maximum capacity: 90 mL (6 x 15 mL)*
Overall Dimensions (H x W x D): 8.75 in. x 11.75 in. x 14 in.
Centrifuge Motor: 1/30 HP, AC
Nominal Acceleration Time: 45 seconds
Protection Breaker: 4 Amp. re–settable
Timer: mechanical, 1 to 30 minutes
accuracy ± 10%
Current Requirement: 1.0 Amps
Voltage Requirement: 115 (±10) Volts
Frequency: 60 Hz
Weight: 13.75 lbs.
Before using any cleaning or decontamination methods except those recommended
by the manufacturer, users should check with the manufacturer that the proposed
method will not damage the equipment. See page 7, (bottom), for the recommended
cleaning solutions.
Any use other than those specified by the Manufacturer is explicitly prohibited.
*
Maximum sample density is 1.15 grams / mL,
(water density = 1.0 grams / mL)
Made in the USA by
Page 10
200 Shadylane Drive • Philipsburg, PA 16866
Phone: 814-342-6205 or 814-692-7661 • Fax: 814-692-7662 • www.druckercompany.com
WARRANTY:
The Drucker Company warranties that this centrifuge is free
from defects in workmanship and parts for 2 years.
