15

14

OPERATING

CHARGING THE BATTERY

The two-dog unit

operates just like the

single-

dog unit. The difference is in the transmitter
where a toggle switch allows you to select either
collar.

The toggle switch is color-coded with black and
orange to match the black and orange collar
straps. The orange collar emits a low tone double
beep and the black collar gives a high tone single
beep so you can distinguish between dogs when
they are out of sight.

The two-dog models have a toggle switch on

the face of the transmitter located above the
“Nick” button. The toggle switch allows for
selection of either collar.

Set the toggle switch on the orange position

to select the orange collar and the black position
to select the black collar.

ORANGE COLLAR

BLACK COLLAR

double beep with low tone

single beep with high tone

TWO DOG UNIT

The battery charger and charging cables

allow you to charge both the transmitter and
receiver at the same time. The battery charger is
designed for a 120-volt wall outlet. (European
230-volt AC chargers and 12-volt field charger
for your automobile are also available.)

To use the battery charger for the two-dog

unit, combine both sets of battery charging
(splitter) cables as shown. This enables you to
charge the transmitter and both receivers at the
same time.

CHARGING THE BATTERIES

Charging Cable

120 volt
Charger

Wall Outlet

Two-dog unit only
