Group Controls— Section 1

The Selection Valve (A1) at the top of the section selects the type of

pressure input for the top of the burette assembly. It can select

VACUUM (Regulated), VENT (to atmosphere), OFF (closed) or

PRESSURE (controlled by the Regulator below it).
The Pressure Regulator (R1) supplies a regulated pressure for the burette

assembly in this section. The regulator in section 1 is different than the

regulators in sections 2 and 3. It has a bias feature, which when turned to

the Bias On (BA) setting, adds the pressure set in Section 2 to Section 1.

When the Bias is on, adjusting pressures with the Section 2 Regulator (R2),

will maintain the differences in pressure between Section 1 and 2 in direct

proportion to the original Section settings. When using the knob to adjust

the pressure it will not turn as easy as the standard type regulator.
To monitor the pressure being set on the regulator there is a Toggle Valve

(T1) directly below the regulator, which is used to connect the regulator to

a pressure read out. To check the pressure while adjusting the regulator lift

the toggle and read the pressure on the digital display located at the top

of the Master Controller. Only one pressure can be monitored at a time.

The Toggle Valve (T1) should be closed after checking the pressure.
The Burette Assembly (B1) has one port at the top, which is connected

to both the external and internal side of the burette. The bottom of the

Burette Assembly has two outlets, one connected to the external side

and one connected to the internal side of the burette. The Burette

Assembly in Section 1 comes with a 50cc burette readable to 0.1cc.
The External Valve (E1) is connected to the External Port and to the

Cell (C1) Quick-Connect. When the valve is turned to External,

water can flow from the external side of the Burette to the Cell (C1)

Quick-Connect.
The Burette Valve (V1) is connected to the burette and to the Cell (C1)

Quick-Connect. When the Valve is turned to Burette, water can flow from

the burette to the Cell (C1) Quick-Connect. The External and Burette

Valves can be opened at the same time and the water levels on both

sides of the burette should be about the same level.

R1

R2

BA

B1

C1

V1

T1

A1
