Modem Port Plug
Dell™ Latitude™ E6510 Service Manual
Removing the Modem Port Plug
1.
Follow the procedures in
Before Working Inside Your Computer
.
2.
Insert a paper clip into the release hole and remove the modem port plug from the computer.
Replacing the Modem Port Plug
To replace the modem port plug, slide the modem port plug back into the modem port.
Back to Contents Page
WARNING:
Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
NOTE:
You may need to install Adobe™ Flash Player™ from Adobe.com in order to view the illustrations below.
