Display Bezel
Dell™ Latitude™ E6510 Service Manual
Removing the Display Bezel
1.
Follow the procedures in
Before Working Inside Your Computer
.
2.
Remove the
battery
.
3.
Remove the
access panel
.
4.
Remove the
hinge covers
.
5.
Remove the
display assembly
.
6.
Starting from the bottom, gently pry the bezel inside out from the display assembly.
7.
Remove the bezel from the display assembly.
Replacing the Display Bezel
To replace the display bezel, perform the above steps in reverse order.
Back to Contents Page
WARNING:
Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
NOTE:
You may need to install Adobe™ Flash Player™ from Adobe.com in order to view the illustrations below.
