LED Cover
Dell™ Latitude™ E6510 Service Manual
Removing the LED Cover
1.
Follow the procedures in
Before Working Inside Your Computer
.
2.
Remove the
battery
.
3.
Press in on the LED cover release latches in the battery bay.
4.
Turn the computer over, with the right side facing up and remove the LED cover from the computer.
Replacing the LED Cover
To replace the LED cover, perform the above steps in reverse order.
Back to Contents Page
WARNING:
Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
NOTE:
You may need to install Adobe™ Flash Player™ from Adobe.com in order to view the illustrations below.
