Programming WM5 96
This menu allows you to set a power value (installed power) that, in the
measuring phase, will represent 100% of the graph indicator “W%”
present in the “P00” page (in the fourth quadrant).
Select INS. POWER ?
(1) by means of the “ ” keys and confirm
with the “S” key. Then enter the full scale value by means of the “
” keys and confirm with “S”.
The instrument shows the maximum and minimum limit of the
value available for the full scale of the W% graph. a
Installed power
15
WM5-96 Instruction Manual
********** MMAAIINN MMEENNUU **********
RREEVV.. 11..44..22..66 ((AAVV55))
CT RATIO
VT-PT RATIO
DMD/AVG CALCUL.
INSTALLED POWER
********** MMAAIINN MMEENNUU **********
RREEVV.. 11..44..22..66 ((AAVV55))
CT RATIO
VT-PT RATIO
DMD/AVG CALCUL.
INSTALLED POWER
INS. POWER ? 1 000 W
min 1000 W
max 9999MW
123...
a
1
2
> 2s
> 2s
Go back
Confirm
Measure
