Multitariff setup with digital inputs
If “remote tariff selection: activated” has been selected,
then only the “Start date” and “End date” of the winter/sum-
mer period need to be saved, as circled above.
PQTSoft Remote
Configuration
29
23
PQTSoft Remote
22
Configuration
Digital input working mode setup
8
12
The WINTER and SUMMER time periods are con-
ventional seasons mainly used to manage in the
best way the different energy costs during the year.
The reminds at steps a), b), c) d) on page 20 are
also valid for the MULTI TARIFF function.
In the SINGLE TARIFF, only one period exists, referred to the
whole year.
In the DUAL TARIFF, the “year” can be divided into two peri-
ods: whole year and holidays.
In the multitariff, the “year” can be divided into 3 periods:
winter, summer and holidays.
H
OW THE REMOTE TARIFF SELECTION IS CARRIED OUT
C
HANNEL
3
SLOT
A C
HANNEL
3
SLOT
C A
CTION
Open
Open
Tariff 4
Open
Close
2 Winter / 3 Summer *
Close
Open
1 Winter / 2 Summer **
Close
Close
Tariff 4
C
HANNEL
2
SLOT
A (if A2 is activated as GAS): If it is closed, the
day GAS tariff is selected, if it is open, the night GAS tariff is
selected.
* PQT-90 applies tariff 2 in the winter period and tariff 3 in the
summer period.
** PQT-90 applies tariff 1 in the winter period and tariff 2 in the
summer period.
Example of winter day division:
On the picture below four different tariffs are shown which
are coupled to seven different periods of the day.
trf
Fine
Inizio
INVERNO
1
OO:OO O6:OO
2
O6:OO O8:OO
3
O8:OO 1O:OO
TARIFFA
1
trf1
24
6
12
18
2
4
8
10
14
16
20
22
trf2
trf2
trf3
trf3
trf4
trf1
trf
INVERNO
2
1O:OO 16:OO
3
16:OO 18:OO
4
18:OO 21:OO
TARIFFA
2
1
21:OO OO:OO
Inizio Fine
