Example 3. Fraction Collection.

Placed downstream of a column, the V9-8 or AV9-8 may be used as an eight-place fraction collector either for

separations which generate large volume fractions or separations where a fraction collector is not appropriate.

For this example, 1/16" OD/0.020" ID Tefzel tubing is recommended.

Valve maintenance and repair

Model V9-8 and AV9-8 valves should be rinsed with water following use with aqueous buffers, or 20% ethanol

following use with non-aqueous solutions. Never allow salt solutions to dry inside the valve. For repair of

Model V9-8 and AV9-8 valves, contact your local Bio-Rad office.

Ordering Information

750-0403

Stream Select Valve, V9-8

750-0408

Automated Stream Select Valve, AV9-8

750-0602

1/16" OD/0.020" ID Tefzel tubing, 30 feet

750-0603

1/8" OD/0.062" ID PTFE tubing, 15 feet

1

2

3

4

5

6

7

COLUMN

GRADIENT

PUMP

1

2

3

4

5

6

9

7

8

FRACTION #1

FRACTION #2

FRACTION #3

FRACTION #4

FRACTION #5

FRACTION #6

FRACTION #7

FRACTION #8

LOAD

POSITION

V7-3 OR AV7-3

V9-8 OR AV9-8

4106040 Rev C
