4–14

Compaq Prosignia Desktop 340 Series Computer

Removal and Replacement Procedures

4.8 Memory Module

1. Perform the preparation procedures.

2. Remove the hood.

3. Remove the power supply.

4. Release the latches 1 at each end of the DIMM socket and unplug the DIMM 2 from the

system board.

To replace the memory module, reverse this sequence.
