Installing the BRIM-F6
BRIM-F6 User’s Guide Page 2-3
Figure 2-2. Installing FPIMs
2.3 Installing the BRIM-F6
This section contains procedures on how to install a BRIM-F6 to upgrade
or change the capabilities of a device’s motherboard.
Note: Cabletron provides disposable wrist straps and faceplate and
standoff screws in both the BRIM package and on devices that support
BRIM technology.
You can install a BRIM-F6 in any device that supports BRIM technology
(e.g., EMM-E6, ESXMIM, NBR-420/620, or MicroMMAC). The
following subsections provide instructions for installing a BRIM-F6 in a
MIM or in a stand-alone hub. Refer to specific MIM or hub
documentation for exact BRIM slot and connector locations.
BRIM-F6
XMT
PWR
RCV
STS FPIM A
WRP
LNK
TWR
LNK
RESER
VED FOR FPIM
FPIM B
RESER
VED FOR FPIM
RESER
VED FOR FPIM
BRIM-F6
XMT
PWR
RCV
STS FPIM A
WRP
LNK
TWR
LNK
FPIM B
Standoffs
FPIM Screws
FPIM Connector
