HB-0502-03 17
SPECIFICATION
PHYSICAL PARAMETERS
Construction
High impact ABS plastic
Window Acrylic
Display Analogue dial and pointer
Back-lit Liquid Crystal Display:
Digits: 12mm 0.47"
Dimensions 110 x 110 x 25.4mm 4 x 4 x 1"
Requires 65mm 2.6" depth behind
bulkhead for display barrel.
Weight 0.3 kg 0.66lbs
ENVIRONMENTAL
Operating Temp
-10 to +55 0 C @ 93%RH
+14 to +131 0 F @ 93%RH
Storage Temp -25 to +70 0 C @ 95%RH
-13 to +158 0 F @ 93%RH
Humidity Up to 95%RH
Sealing
Fully sealed front, suitable for bulkhead cockpit
mounting. Vented barrel to prevent condensation.
ELECTRICAL
Power Supply
12V DC nominal (10 to 16V)
Operating Current 40mA typical, 100mA illuminated
Protection Connect via external 5A fuse or circuit
breaker.
CABLES AND CONNECTIONS
Connection to adjacent units is via cable tails fitted with either
a plug or a socket. Extension cables are available from your
dealer. The cable tails carry power and NMEA data between
units.
ALARM
There is no internal audible alarm
NMEA OUTPUT SENTENCES
$IIHDM Heading
$IIVHW
Speed and Heading
$IIDBT Depth
$IIVWR
Apparent wind angle and speed
$IIMTW Sea temperature
