Installation | NSPL-400 User Manual
• The NSPL-400 is fully waterproof to ingress protection rating IPx7,
however it is recommended that the NSPL-400 is not subjected to
extended periods of exposure to spray or submersion.
• It is acceptable to mount the NSPL-400 either vertically or horizon-
tally.
• The VHF antenna splitter must be installed in a ‘below decks’ envi-
ronment.
• The NSPL-400 should be mounted in a location where the indicators
are readily visible as these provide important information on the
status of the NSPL-400.
Fig. 5 Dimensions
52 mm
152 mm
135 mm
98 mm
47 mm
Figure 4 NSPL-400 dimensions
