Great Plains Disk Harrow Field Update Disk Leveler - Manual

Great Plains Mfg., Inc. Installation Instructions
2/05/2008 SeriesI 3323DH-4336DH Leveler Update 557-330M
1
Disk Harrow Field Update
Disk Leveler
Models: Manual Level Turnbuckle Kit Numbers
Hydraulic Level Kit Numbers:
• 3323
557-323V UPDATE KIT 3323DH MAN LEV 557-324V UPDATE KIT 3323DH HYD LEV
• 3326
557-325V UPDATE KIT 3326-3329DH MAN LEV 557-326V UPDATE KIT 3326-3329DH HYD LEV
• 3329
557-325V UPDATE KIT 3326-3329DH MAN LEV 557-326V UPDATE KIT 3326-3329DH HYD LEV
• 4330
557-327V UPDATE KIT 4330-4336DH MAN LEV 557-328V UPDATE KIT 4330-4336DH HYD LEV
• 4333
557-327V UPDATE KIT 4330-4336DH MAN LEV 557-328V UPDATE KIT 4330-4336DH HYD LEV
• 4336
557-327V UPDATE KIT 4330-4336DH MAN LEV 557-328V UPDATE KIT 4330-4336DH HYD LEV
General Information
These instructions explain how to install
the Disk Leveler Update Kits. If your Disk has
the manual level (turnbuckle) option, then
follow the instructions for the manual level kit.
If your Disk has the hydraulic level (cylinder)
option, then follow the instructions for the
hydraulic level kit.
Manual Update
Refer the Disk Harrow operator’s
manual for detailed information on safely
precautions. Refer to parts manual for part
identification.
556-100M Operator’s Manual
556-100P Parts Manual
Before You Start
For safety it is best to park machine on
level concrete floor. Lower the disk blades to
the ground and relieve all hydraulic pressure
from all circuits. Review these instructions and
make sure you understand where and how the
components are installed, and which existing
parts are removed or re-used.
Tools Required
ƒ Basic Hand Tools
ƒ Cutting Torch or Cutoff wheel
3/19/2008
