22 Front Page Part Lists
403-533M Front Page Part Lists 09/27/2011
APPENDIX
New Parts
The part call-out numbers in this list match all Figures in
these installation instructions. Part descriptions match
those in your updated Parts Manual. Quantities are units (“ea”).
Kit Content
Abbreviations
EOD
403-531A Air-Pro
®
Test Stand Meter Mount Kit
Callout Quantity Part Number Part Description
11 1 403-533M MANUAL METER TEST STAND
12 1 403-271K AIR METER ASSY, 25 SER
13 1 403-301S SEED TUBE AM TB,CLIP & SENS
14 1 403-528H TEST STAND PIN DRIVER F/ 19
15 1 403-530H RH METER MAX MOUNT FOR AIR
16 1 403-532K METER MOUNT & CLAMP ASY
17 1 803-374C NUT HEX JAM 7/16-20 PLT
18 1 817-613C SEED DISCHARGE HOSE 42
19 1 817-868C TEST STAND FUNNEL
20 1 830-414C CP KENT CAT4 M QD X 1/4 HB
21 1 830-415C CP KENT CAT4 F QD X CAP
22 1 891-122C AD 7/16MORB X 1/4HB BRASS
23 3 990-021R HOSE 1/4 RUBBER AIR
ASSY Assembly MORB Male O-Ring Boss
CAT Category PLT Plated
CP Coupler QD Quick Disconnect
HB Hose Barb RH Right Hand
LH Left Hand TB Tube
