Assembly
The following are step-by-step instructions for
assembling the cart. Begin with Tools Required and
Pre-Assembly Checklist to make sure you have all
necessary parts and equipment. Then proceed with
Remove Cart from Truck. Follow each step to make the
job as quick and safe as possible and produce a properly
working machine.
The cart is shipped via flat bed truck. It is the dealer’s
responsibility to unload the new machine. Unload all
equipment before beginning assembly. Do not attempt
any assembly work while the cart is on the truck.
Tools Required
• Forklift or overhead hoist with 8,000 pound (3600 kg)
capacity
• Hand jack with 4-ton (3600 kg) capacity
• General hand tools
• Jack stands, blocks and safety chain
Pre-Assembly Checklist
1. Read and understand “Important Safety
Information” on page 1 before assembling.
2. Have at least two people on hand while assembling.
3. Make sure the assembly area is level and free of
obstructions (preferably an open concrete area).
4. Have all major components.
5. Have all fasteners and pins shipped with cart.
If a pre-assembled part or fastener is temporarily removed,
remember where it goes. Keep the parts separated
6. Have a copy of the parts manual on hand. If unsure
of proper placement or use of any part or fastener,
refer to the parts manual.
7. Check that all working parts are moving freely, bolts
are tight, and cotter pins are spread.
8. Check that all safety decals and reflectors are
correctly located and legible. Replace if improperly
located or damaged. Refer to Safety Decals under
“Important Safety Information” in the operator’s
manual.
9. Inflate tires to recommended pressure, see “Tire
Inflation Chart” on page 17. Tighten wheel bolts as
specified, see “Torque Values Chart” on page 17.
