2410P and 2420P
118-769M 2012-04-17
42
Seed-Lok Lock Up
Optional Seed-Lok firming wheels provide addi-
tional seed-to-soil contact. The wheels are spring
loaded and do not require adjusting. In some wet
and sticky conditions the wheels may accumulate
soil.
Refer to Figure 56
NOTE: Side gauge wheel and seed meter is re-
moved for clarity.
To lock up Seed-Lok wheels, raise drill. Rotate
lock-up handle (1) 90 degrees down on top of
opener body, see insert in Figure 56. Push up on
Seed-Lok wheel (2) until wheel arm latches up.
Opener disk blades may be sharp. Use caution when
making adjustments in this area.
To unlock Seed-Lok wheels, pull up lock-up han-
dle (1). Seed-lok is spring loaded so it will snap
back into place.
Figure 56
Seed-Lok Lock Up
18282
Push Seed-Lok
up to lock.
Locked
position.
Unlocked
position.
