26 3P806NT Table of Contents Index Great Plains Manufacturing, Inc.
151-143M Table of Contents Index 2011-12-20
Typical
a
3P806NT Weights by Configuration
Trailer Transport
Load Maneuvering Hazard - Use care and planning when
loading or unloading the drill in trailer transport. The rear
casters may turn and force the drill off the trailer.
▲ Make sure the trailer is rated for the load.
▲ Make the trailer is wide enough for the load.
▲ Make sure the load is secured properly.
Loading Trailer
1.
Hitch suitable 3-point tractor with available hydraulic
remote (page 15).
2. Raise drill (page 20).
Loading with Casters Locked
3.
Carefully line-up the tractor, drill and trailer, so that:
a. no turns are needed for the final movement, and
b. the casters are fully reversed.
4. Install caster swivel lock pins (page 23).
5. Carefully back the drill onto the trailer bed.
6. Lower the drill (page 22).
7. Secure the load with cargo straps or chains.
Great Plains recommends locking casters prior to loading for
trailer transport, and leaving them locked for transport and
unloading. This reduces the risk of loading and transport
accidents which could result in significant implement damage.
Unloading Trailer
1.
Check that casters are still locked.
2. Release cargo straps or chains.
3. Hitch suitable 3-point tractor with available hydraulic
remote (page 15).
4. On a narrow trailer, confirm that caster pivot swivel
locks are still in place (page 23).
5. Raise drill (page 20).
6. Carefully tow drill from trailer.
7. Remove caster pivot swivel locks (if engaged,
page 23).
8. Unless arriving at planting ground, install lift-assist
cylinder transport locks (page 20).
a. Weights are for serial number A1057V+, are approximate, and can vary by hundreds of pounds based on material density, press wheel
options, accessories and user modifications. Weight kit figures presume 10 each 100 pound suitcase weights.
All Boxes Empty 4054 lbs 4269 lbs 4386 lbs 4166 lbs 4340 lbs 4500 lbs
1839 kg 1936 kg 1990 kg 1890 kg 1969 kg 2041 kg
Full Main Box and 5078 lbs 5851 lbs 5410 lbs 5190 lbs 5922 lbs 5524 lbs
Full Fertilizer (if present) 2303 kg 2654 kg 2454 kg 2354 kg 2686 kg 2506 kg
All Boxes Empty 5213 lbs 5429 lbs 5546 lbs 5326 lbs 5500 lbs 5659 lbs
with Weights 2365 kg 2462 kg 2516 kg 2416 kg 2495 kg 2567 kg
Full Main Box, Weights, 6237 lbs 7011 lbs 6570 lbs 6350 lbs 7082 lbs 6683 lbs
Full Fertilizer (if present) 2829 kg 3180 kg 2980 kg 2880 kg 3212 kg 3032 kg
32337A
Standard Drill
Option (40)
Drill with
Fertilizer
Drill with NG
(Native Grass)
Drill with SGS
(Small Seeds)
Drill with
Fert. and SGS
Drill with
NG and SGS
Unstable Load Hazard - Do not transport on a trailer of
insufficient width or length. Unless both caster tires are on the
bed, too few openers are supporting the entire drill. The load
may spill, with risk of serious injury or death to anyone
nearby, and certainty of major equipment damage.
Equipment Damage Risk - The drill must be hitched to a
3-point tractor for any movement. Coulter or opener damage
is likely if unhitched movement is attempted. Observe all
hitching precautions.
