33 ST Toolbar
Operating Instructions
AS2108 3M X-PRESS PARKING STAND
IT EM PART NO DESCRIPT ION QT Y COMMENT S
1 P01351 BOLT M16x130 GR. 8.8 2
2 P02008 NUT LOCK M16 2
3 P02485 R CLIP Ø6x120 1
4 P02602 WASHER FLAT M16 4
5 P05207 PIN Ø16x73 1
6 P07543 PLASTIC END CAP 40x40 1
7 P13666 PARKING STAND BASE 1
8 P13667 PARKING STAND LEG 1
9 P13668 RETAINING PLATE 1
