27 ST Toolbar
Operating Instructions
Parts & Assembly
AS2397 ST-BAR 4.0M + MOUNTED X-PRESS
IT EM PART NO DESCRIPT ION QT Y COMMENT S
1 AS2108 3M X-PRESS PARKING STAND 2
2 AS2167 ROLL LINKAGE 2
3 AS2169 DDLIGHT ROLL UNIT 4.0m 1
4 AS2385 ST TOOLBAR 4.0M 1
5 AS2396 4M X-PRESS TO SUIT MOUNTED TOOLB 1
6 P02484 LYNCH PIN CAT 2 3
7 P13111 UPPER LINK PIN 1
8 P13112 LOWER LINK PIN 2
