23 ST Toolbar
Operating Instructions
Parts & Assembly
AS2124 ST TOOLBAR + MOUNTED X-PRESS
IT EM PART NO DESCRIPTION QT Y COMMENT S
1 AS1647 X-PRESS - 3m 3PL ROLL ASSEMBLY DDLIGHT 1
2 AS1649 ROLL LINKAGE 2
3 AS2107 3M X-PRESS TO SUIT MOUNTED TOOLBAR 1
4 AS2108 3M X-PRESS PARKING STAND 2
5 AS2123 ST TOOLBAR 1
6 P02484 LYNCH PIN CAT 2 3
7 P13111 UPPER LINK PIN 1
8 P13112 LOWER LINK PIN 2
