ST Toolbar
Operating Instructions
AS2104
X-PR ESS T IN E ASSEMBLY
IT EM
PART NO
DESCRIPT ION
QT Y
COMMENT S
1
H00230085
BUSH Ø38xØ30x35
2
2
H00230086
BUSH Ø34xØ30x40
2
3
H00230087
BUSH Ø34xØ30x25
1
4
H00230098
BUSH Ø44xØ36x30
1
5
H00310153
BOLT M12x80 CSK SQ. 12.9
2
6
H00350061
NUT LOCK M16
2
7
H00350084
NUT LOCK M12 FLANGED
2
8
H00360072
BOLT M20x80 GR. 8.8
2
USE WITH H34060812
9
H00360075
BOLT M20x110 GR. 8.8
2
USE WITH H34060812
10
H00370060
ROLL PIN Ø10x50
2
11
H00370074
ROLL PIN Ø6x50
2
12
H00370108
WASHER FLAT M16
4
13
H00370109
WASHER FLAT M20
4
USE WITH H34060812
14
H34060801
TINE ARM LH
1
15
H34060803
TINE ARM RH
1
16
H34060806
CLAMP BASE
1
17
H34060807
PIN Ø30x178
1
18
H34060809
SPRING Ø84xØ19x372
1
W
19
H34060812
RETAINING PLATE
1
20
H34060813
BOLT M16x75 GR10.9
2
21
H34060816
SPRING Ø50xØ10x273
1
22
H34060822
BUSH Ø40xØ34x105
1
23
H34060842
SPRING PIVOT
1
24
H34060844
SPRING TOP PLATE
1
25
H34060845
SPRING TUBE
1
26
H34060846
BOLT M24x360 GR8.8
1
27
H34080847
WASHER Ø57xØ26x8
1
28
P02008
NUT LOCK M16
1
29
P02332
WASHER SPRING M20
4
30
P02485
R CLIP Ø6x120
1
31
P02602
WASHER FLAT M16
2
32
P02649
BOLT M16x90 GR. 8.8
1
33
P03115
BOLT M20x60 GR. 8.8
2
34
P03116
BOLT M20x90 GR. 8.8
2
35
P05207
PIN Ø16x73
1
36
P12711
WEDGE COMPLETE
1
37
P12911
TERRAGRIP CONVERTER
1
38
P13093
TINE - ST TYPE
1
39
P13135
POINT KNOCK ON 100mm
1
40
41
42
43
44
45
46
47
48
49
50
