Great Plains ADC2350B Assembly Instructions - Manual (Page 9)

Great Plains Mfg., Inc.
Installation Instructions 9
03/05/2009 166-255M
This manual covers the installation of several different
hold-down kits. Parts are listed for each kit separately.
Quantities are units (“ea”).
The part call-out numbers in this list match all Figures in
these installation instructions. Part descriptions match
those in your updated Parts Manual.
166-247A Kit Contents
Callout
Quantity
in Kit
Part
Number Part Description
1 166-255M MANUAL 2350B AUGER CARRIER UPD
2 166-187H AUGER CARRIER PULL BEHIND
2 166-188H AUGER TRANS LATCH PULL BEHIND
1 166-189H AUGER BALANCE SPRING ANCHOR
1 166-190H 20’ AUGER PIVOT MOUNT WELDMENT
1 800-001C GREASE ZERK STRAIGHT 1/4-28
2 800-285C AUGER LATCH CLAMP
12 802-007C HHCS 5/16-18X3/4 GR5
4 802-034C HHCS 1/2-13X1 1/4 GR5
2 802-045C HHCS 1/2-13X5 GR5
1 802-114C HHCS 3/8-16X2 1/2 GR5
2 802-130C HHCS 1/2-13X2 1/2 GR5
1 802-412C HHCS 1/2-13X2 3/4 FTHD
1 802-469C HHCS 3/4-10X8 GR5 PLT
16 802-888C ELEVATOR BOLT 1/4-20X3/4 PLT
16 803-006C NUT HEX 1/4-20 PLT
16 803-008C NUT HEX 5/16-18 PLT
1 803-014C NUT HEX 3/8-16 PLT
4 803-019C NUT LOCK 1/2-13 PLT
5 803-020C NUT HEX 1/2-13 PLT
1 803-025C NUT HEX 3/4-10 PLT NYLOCK
16 804-006C WASHER LOCK SPRING 1/4 PLT
12 804-009C WASHER LOCK SPRING 5/16 PLT
1 804-013C WASHER LOCK SPRING 3/8 PLT
5 804-015C WASHER LOCK SPRING 1/2 PLT
1 804-093C WASHER FLAT 3/4 HARD ASTMF436
2 804-113C WASHER FLAT 1/2 USS HARD PLT
2 816-562C 8 INCH AUGER REST PAD
2 816-570C 8 INCH AUGER CLAMP PAD
- - Existing See next two pages.
