Page 14
113-777M
2/28/2006
Great Plains Mfg., Inc.
Flat Fold Marker Option
14
113-774K 40P LH MARKER HDW BUNDLE
Your kit includes:
1
113-686D
3S-4000 MARKER HINGE PIN LG
1
113-777M
40P MARKER MANUAL
1
113-789D
40P MARKER TRANS REST SHIM
7
502-068D
HYDRAULIC HOSE CLAMP BRACKET
12
800-082C
CABLE TIE .31X21.5 6DIA 120LB
1
802-138C
HHCS 5/16-18X2 1/4 GR5
14
802-172C
HHCS 5/16-18 x 2 1/2 GR5
1
803-011C
NUT LOCK 5/16-18 PLT
2
803-020C
NUT HEX 1/2-13 PLT
4
803-027C
NUT HEX 3/4-10 PLT
2
804-015C
WASHER LOCK SPRING 1/2 PLT
4
804-023C
WASHER LOCK SPRING 3/4 PLT
4
804-025C
WASHER FLAT 3/4 SAE PLT
1
805-004C
PIN CLEVIS 1 X 2 3/4 USABLE
1
806-010C
U-BOLT 1/2-13X2 1/2X 3 1/2
2
806-172C
U-BOLT 3/4-10 X 10 1/32X11 1/2
1
810-058C
VALVE 3/8 NEEDLE
1
811-044C
AD 3/8MNPT
1
811-065C
EL 9/16MJIC 9/16MORB
1
811-151C
AD 9/16MJIC 3/8MNPT
1
811-281C
EL 3/8FNPT 9/16MORB
Qty.
Part No.
Part Description
113-775V 40P LH MARKER HOSE BUNDLE
Your kit includes:
1
811-823C
HH3/8R1 504 9/16 FJIC 3/4 MOR
1
811-824C
HH3/8R1 528 9/16 FJIC 3/4 MOR
Qty.
Part No.
Part Description
