Great Plains Utility Coulter & Vantage I-20 Fertilizer Coulters User Manual
Page 13
7/19/2011
204-308M
11
Parts
1.
803-025C
NUT HEX 3/4-10 PLT NYLOCK
2.
812-031C
CASTING COULTER SPRING WASHER
3.
204-107D
SPRING ROD SLEEVE 1 1/8 OD
4.
807-074C
SPRING 2.25 OD X .5 COIL
5.
817-029C
BUSHING COULTER CASTING
6.
149-963S
COULTR MOUNT, CASTNG ASSY
7.
800-001C
GREASE ZERK STRAIGHT 1/4-28
8.
204-026D
SHANK 1 1/2D X 22 FERT COULT
9.
820-132C
1 1/2 X 22 OFFSET SHANK
10.
805-043C
PIN SPIROL 3/8X2 1/2 PLAIN
11.
204-075H
COULTER SPRING ROD WLDMT
12.
801-040C
SCREW SQ HD 5/8-11 X 1 CUP PT
13.
149-162H
COULTER STOP WELDMENT
14.
804-039C
WASHER FLAT 1 1/4 SAE PLT
15.
805-021C
PIN COTTER 1/4 X 2 PLT
16.
803-181C
NUT HEX FLANGE LOCK 3/4-10 PLT
17.
817-051C
SWING ARM BUSHING
18.
149-181E
CLTR SWG ARM WD REPLBY149-181E
19.
816-009C
OIL SEAL DOUBLE LIP
20.
822-021C
BEARING CONE LM-67048
21.
822-020C
BEARING CUP LM-67010
22.
802-106C
RHSNB 1/2-13X1 1/2 GR5
23.
200-039V
COULTER HUB & CUP ASSY
24.
804-055C
WASHER SPINDLE - 7/8
25.
820-018C
COULTER BLADE FLUTED
26.
804-015C
WASHER LOCK SPRING 1/2 PLT
27.
803-020C
NUT HEX 1/2-13 PLT
28.
200-001D
HUB GREASE CAP
29.
805-017C
PIN COTTER 3/16 X 1 3/4 PLT
30.
803-029C
NUT HEX SLOTTED 7/8-14 PLT
31.
200-002S
COULTER HUB PACKAGE
32.
838-482C
DECAL GP PLANTING COMPONENTS
Ref.
Part No.
Description
