Great Plains Utility Coulter & Vantage I-20 Fertilizer Coulters User Manual
Page 11
7/19/2011
204-308M
9
Parts
1 149-044D COULTER
STOP
2 149-558D COULTER
SPRING
WASHER
3
149-559D
SPRING 2.25 O.D. X .5 COIL
4
204-379S
COULTER HUB PACKAGE
5
249-051H
CLTR SWING ARM WLMT
Used on RH.
5
249-237H
LH COULTER SWING ARM WLMT
Used on LH.
6
249-225S
PVT CLTR CASTING MOUNT ASY RH Used on RH.
6
249-226S
PVT CLTR CASTING MOUNT ASY LH Used on LH.
7
800-001C
GREASE ZERK STRAIGHT 1/4-28
8
800-164C
SNAP RING 3/4 EXTERNAL HEAVY
9
800-177C
SNAP RING EXT 1 1/4 HEAVY
10
801-083C
SCREW SET 5/8-11X1 1/2 GR8 CUP
11
802-214C
RHSNB 1/2-13X1 1/4 GR5
12
802-718C
EYE BOLT 3/4-10X14 3/4 LG SP
13
803-020C
NUT HEX 1/2-13 PLT
14
803-023C
NUT HEX JAM 5/8-11 PLT
15
803-029C
NUT HEX SLOTTED 7/8-14 PLT
16
803-048C
NUT HEX JAM 3/4-10 PLT
17
804-015C
WASHER LOCK SPRING 1/2 PLT
18
804-055C
WASHER SPINDLE - 7/8
19
804-156C
WASHER MACH 1 1/4X3/4X14GA
20
804-165C
WASHER MACH 1 7/8X1 1/4X 14GA
21
805-017C
PIN COTTER 3/16 X 1 3/4 PLT
22
805-043C
PIN SPIROL 3/8X2 1/2 PLAIN
23
805-331C
COULTER SPRING GUIDE TUBE
24
817-513C
BUSHING 1X3/4X1 1/8 FLG HD
25
838-482C
DECAL GP PLANTING COMPONENTS
26
200-039V
COULTER HUB & CUP ASSY
27
816-009C
OIL SEAL DOUBLE LIP
28
822-021C
BRG CONE 1.25ID LM-67048
29
822-020C
BRG CUP LM-67010
30
820-018C
COULTER BLADE FLUTED
31
200-001D
HUB GREASE CAP
32
204-026D
SHANK 1 1/2D X 22 FERT COULT
33
820-132C
1 1/2 X 22 OFFSET SHANK
Ref.
Part No.
Description
