21
Section 2 Implement Assembly and Setup
7/28/10 Model 1150 1995 - 1997 167-058M
Great Plains Mfg., Inc.
Implement Lift
Cylinder Hydraulic Hoses Refer to Figure 2-3 and Figure 2-4. Install the hydraulic
hoses in place on the lift wheels. Note the hose lengths
listed and be sure to use the correct length of hose in each
location. Install the longest hose first and work down to the
shortest hose length.
The row openers in some locations have hose clips (#1)
mounted on them, refer to Figure 2-5. Hydraulic hoses should
always be routed through the clips to prevent damage.
NOTE: The SAE o-ring and JIC 37˚ flare type hose
connections do not require sealant for reconnecting.
They do not require high torque for a good seal.
