E-5
Contact Measurements Ranges (continued):
RATES: Wheel Circumference:
Yards per Hour 10cm: 3.281 to 131,233 YPH
12 in: 10.000 to 240,000 YPH
Miles per Hour 10 cm: 0.002 to 74.564 MPH
12 in: 0.006 to 136.36 MPH
Centimeters per Second 10 cm: 0.084 to 3,333.3 CM/S
12 in: 0.21 to 3,048.0 CM/S
Centimeters per Minute 10 cm: 5.000 to 200,000 CM/M
12 in: 15.240 to 365,760 CM/M
Centimeters per Hour 10 cm: 300.00 to 999,990 CM/H
12 in: 914.40 to 999,990 CM/H
Meters per Second 10 cm: 0.001 to 33.333 M/SEC
12 in: 0.003 to 60.960 M/SEC
Meters per Minute 10 cm: 0.050 to 2,000.0 M/MIN
12 in: 0.153 to 3,657.6 M/MIN
Meters per Hour 10 cm: 3.000 to 120,000 M/H
12 in: 9.144 to 219,460 M/H
TOTALIZER:
Counts: 0 to 999,999
Scale Totals in Inches, Feet, Yards, Centimeters or Meters
Input: Internal or External optics or linear contact wheel
Timer Specifications:
Minutes:Seconds.Tenths to 99:59.9
Accuracy: ±0.2 second
Resolution: 0.1 second
S-18
6. Entre
selección de
Unidades
7. Seleccione
Unidades
8. Guardar y
avanzar
Rotacional: REV
Linear: INCH (pulgadas),
FEET (pies), YARDS
(yardas), CM, METER
(metros)
Differentes opciones se despliegan
para operación Interna o Externa
ROS Interno o Externo: RCA Externo:
COUNT
(Conteo)
Solamente
O Repita hasta que
las unidades
deseadas se
despliegan
COUNT o REV Unidades
Lineares
O
8a. Entre
selección de
Rueda
8b. Seleccione
Rueda
8c. Guardar y
avanzar
Solo para Unidades Lineares:
O Cambie
entre 10CM
y 12IN (12
pulgadas)
La última
rueda
seleccionada
se despliega
