12 Technical Support: 800.283.5936
SPECIFICATIONS
System Requirements
windows XP
windows vista
windows 7
Connections
USB:
version 2.0 Compatible
Type: Mini-b female
Controls
Call Control (Hook)
volume Up
volume down
Microphone Mute
Audio
Speaker:
bandwidth: 220 Hz - 14 kHz
Max Output Level: 82 db SPL @ 1 foot (0.30 meter)
Microphone:
bandwidth: 50 Hz - 7.75 kHz
Processing
full duplex
Acoustic Echo Cancellation (AEC)
Noise Cancellation (NC)
Automatic Level Control (ALC)
Power
USB:
5 vdC @ 500 mA Maximum
Environmental
Operating Temperature:
41 - 104 ° f (5 - 40 ° C)
Mechanical
dimensions (w x d x H):
3.8” x 4.1” x 1.8”
(9.7 cm x 10.4 cm x 4.6 cm)
weight:
0.55 lbs. (0.25 kg)
Compliance
RoHS
REACH
fCC Class b Part 15
ICES-003
CE Listed
UL Listed
Model Numbers
910-159-256 CHAT 60-U
CHAPTER 5: APPENDIX
