2
Table 2 — Contents of Accessory Kit
*Requires two kits.
PART NUMBER QUANTITY DESCRIPTION USAGE
00PPN500000600A 2
5 /
8
in. tube assembly with 90-degree
bend and 1 in. — 14 O-ring seal nut
Blank end of the cooler except in
30RB110 circuit A
00PPN50001000A 2
Solenoid valve with 1 /
2
in.
ODF connections
All
00PSN500023900A 2
5 /
8
in. beaded tube with 1 /
2
in. swage
(used with 1 1 /
8
in. discharge lines)
30RB060,070,110,120, circuit A and
30RB080-100 circuits A and B
00PSN500024000A 1 5 /
8
in. beaded tube with 1 /
2
in. swage 30RB060,070 circuit B
00PSN500024400A 2
5 /
8
in. beaded tube with 1 /
2
in. swage
(used with 1 5 /
8
in. discharge lines)
30RB110,120 circuit B and
30RB130-390 all circuits
00PSN500023600A 4 Tube support bracket
30RB060-110, circuit A (1 required)
30RB120,130 (2 required)
30RB150 (3 required)
30RB160-390 (4 required)
00PPN500000302A 8 M6 screw All, mount tube support brackets
00PPN500000401A 7 No. 10 screw All, mount tube clamps
EP71BA181 2 1 /
2
in. ball valve
All, put in discharge line after solenoid
valve so circuit can be isolated
30GX503492 2 1 in. — 14 ORS by 1 / 2 in. NPT adapter
All at blank end of cooler except
30RB110 circuit A
KA66AA050 5 1 /
2
in. tube clamp
30RB060-110 (1 required)
30RB120,130 (2 required)
30RB150 (3 required)
30RB160,170,190, 315-390* (4 required)
30RB210-300* (5 required)
KA66AA062 2 5 /
8
in. tube clamp All, one per circuit just before solenoid
SF703318 2 Cable assembly All, one per circuit
R31.75
[1.25]
152.40
[6.00] 1in.-14 ORS NUT MUST
MATE CORRECTLY
WITH CARRIER
ADAPTER
30GX503492
65.77
[2.59]
126.73
[4.99]
12.33
[0.49]
MIN.
Ø 12.7 [.50] SWAGE
R25.40
[1.00]
20.11 MIN.
[0.79]
BEAD
5.60
[0.22]
50.80
[2.00]
126.73
[4.99]
12.33
[0.49]
MIN.
Ø 12.7 [.50] SWAGE
BEAD
R25.40
[1.00]
5.60
[0.22]
58.16
[2.21]
20.11 MIN.
[0.79]
00PSN500023900A
00PSN500024400AA
00PPN500000600A
NOTE: DIMENSIONS ARE IN MM [IN].
BEAD
00PSN500024000A
Ø 12.7 [.50] SWAGE
5.60
[0.22]
123.98
[4.88]
222.98
[8.78]
12.33
[0.49]
MIN.
NOTE: Dimensions are in mm [in.].
Fig. 1 — Dimensions of Tubes Provided in Accessory Kit
