Turbomachinery Package Specification Titan 250 Generator Set
Table 10. Air Inlet System Specifications
Air Inlet System
Pressure Drop Less Than 102 mm (4 in.) H
2
O with a Clean Air Filter
Ducting Loads Should Not Be Applied In Any Direction
Prefilter and Barrier Inlet Air Filter
Pressure Drop
Clean 44 mm (1.75 in.) water
Fouled 127 mm (5 in.) water
Self-Cleaning Barrier Type Air Filter
Fluid Clean-Dry Air
Air Quality See Note (a)
Minimum/Maximum Regulated Pressure Range 552 to 758 kPag (80 to 100 psig)
Intermittent Flow Rate 0.5 nm 3 /min (18 scfm)
Pressure Drop (Clean) 25 mm (1.0 in.) water
Marine-Type Air Filter
Pressure Drop (Clean) 53 mm (2.1 in.) water
Construction Materials
Prefilter/Barrier Carbon Steel (Standard)
316L Stainless Steel (Optional)
Insect Screen Carbon Steel (Standard)
316L Stainless Steel (Optional)
Self Cleaning Barriers Carbon Steel (Standard)
316L Stainless Steel (Optional)
Marine-Type Air Filter 316L Stainless Steel (Standard)
Air Inlet Silencer Carbon Steel (Standard)
316L Stainless Steel (Optional)
Air Inlet Ducting Carbon Steel (Standard)
316L Stainless Steel (Optional)
Air Inlet Support Structure Carbon Steel (Standard)
Applicable Product Information Letters
Solar’s Product Information Letter PIL 054 OSHA Noise Requirements
Solar’s Product Information Letter PIL 178 Salt Ingress Protection for Gas Turbines
Notes :
(a) The particle size in the air stream should not exceed 10μm. Since it is impractical to remove
100% of all particles larger than 10μm, this is defined as ß10 > 100, or 99% efficient. Oil or
hydrocarbon content should not exceed 1 ppm. The dew point at line pressure shall be at
least 6
°C (10°F) below the minimum temperature to which any part of the air system is
exposed or between 1.6 °C and 60°C (35°F and 140°F). Air should be free of all corrosive
contaminants, hazardous gases, flammables, and toxics.
© 2008 Solar Turbines Incorporated. All rights reserved. TPS250GS/908 - Preliminary
54
