Turbomachinery Package Specification
Titan
250 Generator Set
Construction Materials
Piping, Manifolds, and Tubing < 10.2 cm (4 in.)
Note (a)
316L Stainless Steel (Unless Otherwise Specified)
Piping, Manifolds, and Tubing > 10.2 cm (4 in.)
Note (a)
Carbon Steel (Unless Otherwise Specified)
Piping Interface Connections
316L Stainless Steel (Unless Otherwise Specified)
Flange Assembly Hardware
316L Stainless Steel
Pipe Support Brackets
Carbon Steel (Standard)
316L Stainless Steel (Optional)
Pipe Flexible Couplings
Carbon Steel (Standard)
316L Stainless Steel (Optional)
Tubing Dual Ferrule Compression Fittings
316L Stainless Steel
Sliding Lube Oil Drain Couplings and Plates
Carbon Steel (Standard)
316L Stainless Steel (Optional)
Lube Oil Vent Flame Arrestor
Aluminum
Electrical System Certifications
NEC
Class 1, Group D, Division 1 or 2
CENELEC
Zone 1 or 2, Group II
CE, ATEX
Zone 2, Group II
Three-Phase Package Motors
Optional Motor Voltage Ratings
380, 400, or 415 VAC, 50 Hz
460 VAC 60 Hz
Single-Phase Battery Charger
Optional Battery Charger Voltage Ratings
220, 230, 240, 380, 400, 415, 440, 460, or 480
VAC, 50 Hz or 60 Hz
Single-Phase Lighting and Space Heater Voltage
Optional Package Lighting and Space Heater
Voltage Ratings
120, 220, 230, or 240 VAC, 50 Hz or 60 Hz
Ingress Protection (IP) Ratings
Onskid Junction Boxes
IP56 to IP66
Control Console
IP50
Battery Charger, NEC
IP22
Battery Charger, CE
IP31
Solar’s Applicable Engineering Specifications
ES 9-56
Fusion Welding
ES 9-58
Standard Paint Program – Turbomachinery
ES 1593
Guidelines for NEC Compliance of Solar’s Product Lines: Class I, Group D, Division 1
and Division 2
ES 1762
Standards and Practices for Electrical Systems for Gas Turbine Packages Installed In
Hazardous Areas (CENELEC/IEC Standards – European ATEX Directive 94/9/EC)
ES 2201
Auxiliary Air
ES 2231
Standards and Practices for The Design and Installation of Cable Channels and TC
Rated Cables Installed In Class 1, Division 2 Hazardous Areas
Solar’s Applicable Product Information Letters
PIL 127
Product Certification
Notes:
(a)
All package piping is fabricated from 316L stainless steel with the exception of lube oil vent
lines and any piping welded directly to a carbon steel lube oil tank or tank cover.
© 2008 Solar Turbines Incorporated. All rights reserved.
TPS250GS/908 - Preliminary
