Turbomachinery Package Specification Titan 250 Generator Set
Table 7. Turbotronic 4 Control System Specifications
Control System Components
Control Processor Allen-Bradley ControlLogix controller
Input/Output Modules Allen-Bradley Flex I/O modules
Generator Control Allen-Bradley/Basler Electric Combination
Generator Control Module
Vibration Monitoring System Bently Nevada 1701 FieldMonitor
Internal Control System Network ControlNet 1.5
Human Machine Interface (HMI) Solar’s TT4000 Display & Monitoring System
Fire & Gas Monitoring System (Enclosed
Packages) Det-Tronics Eagle Quantum Premier System
Temperature & Vibration Monitoring
Gas Turbine Refer to Section 3
Gearbox Refer to Section 4
Generator Refer to Section 5
Offskid Control Console Dimensions
One-Bay Control Console
Height 2286 mm (90 in.)
Width 914 mm (36 in.)
Depth 800 mm (31.5 in.)
Approximate Weight 570 kg (1250 lb)
Two-Bay Control Console
Height 2286 mm (90 in.)
Width 1448 mm (57 in.)
Depth 800 mm (31.5 in.)
Approximate Weight 680 kg (1500 lb)
Supervisory Interface Modules
ControlNet 1.5
Cables RG-6U Coaxial
Maximum Cable Length 1000 m (3300 ft)
Transmission Protocol Common Industrial Protocol (CIP)
Transmission Speed 5 Mbps
Ethernet
Cables 10BaseT
Network Length
100 m (330 ft) To Nearest Hub
Transmission Protocol CIP Protocol with TCP/IP
Transmission Speed 10 Mbps
Data Highway Plus
Cables DH+ Twisted Pair
Maximum Cable Length 3000 m (10,000 ft)
Transmission Protocol CIP or DF1 Protocol
Transmission Speed 57.6 bps
Modbus
Cables RS232C, RS422, or RS485
Cable Length RS232C: 15 m (50 ft)
RS422 and RS485: 1200 m (4000 ft)
Transmission Protocol Subset of Modbus RTU Protocol
