Quoizel QF1398SMM Quoizel Fixture User Manual
Page 2
QF1398SMM
FINISH: MOTTLED SILVER
1
PART NUMBER
NOTE: ALL DIMENSIONS ARE ROUNDED UP TO THE NEAREST 1/2"
REPLACEMENT PART DESCRIPTION
REQ.
NO.
2 of 5
(3) 60W Medium
Base Bulbs
(Not Supplied)
GND
2.4mm
13Ga
QUOIZEL
R
16” Dia.
5” Dia.
1”
4”
12”
16” Dia.
2
3
11398SMMQF
BASE QF1398SMM
1
G3500DI
DIFFUSER 15"D
1
S1485MC
SHADE MICA 16"D
1
1
2
3
